SPECIFICATIONS
POWER SUPPLY
Working Voltage
9 – 16 VDC
Remote Input Voltage
9 – 16V
Remote Output Voltage
12.8V (0.5A)
Fuse Size
2 Amp
DSP Speed
147 MIPS
DSP Precision
32-Bit
DSP Accumulators
72-Bit
AUDIO
THD + N
< 1%
Frequency Response
20Hz-20KHz (+/- 0.5dB)
Signal to Noise Ratio @ A Weighted
>100dB
Input Sensitivity
0.2 – 9V
Input Impedance
20kΩ
Maximum Pre-Out Level (RMS)
8V
Pre-Out Impedance
200Ω
AUDIO ADJUSTMENT
Crossover Frequency
Variable HPF/LPF 20Hz to 20KHz
Crossover Slope
Selectable 6/12/18/24/36/48 dB/Oct
Equalization
31 Bands Parametric
Q Factor
Selectable 0.05 to 20
EQ Presets
Yes POP/Dance/Rock/Classic/Vocal/Bass
User Presets
Yes Basic / Advanced
DIGITAL TO ANALOG CONVERSION (DAC)
Precision
24-Bit
Dynamic Range
108dB
THD + N
-98dB
ANALOG TO DIGITAL CONVERSION (ADC)
Precision
24-Bit
Dynamic Range
105dB
THD + N
-98dB
INPUT | OUTPUT
High / Low Level Input
Up to 8 channel
Low Level Output
Up to 8 Channel
Type
RCA (Female)
DIMENSIONS / SHIPPING INFO
Length
6.37″ / 162mm
Depth
3.6″ / 91.5mm
Height
1.24″ / 31.7mm
Dimensions Single Box L x W x H (Inches)
8 x 4.75 x 3.25
Weight (lb)
1
M/C Dimension L x W x H (Inches)
17 x 14 x 15
M/C Weight (lb)
30
M/C Qty
24 Pcs
DS18 DSP8.8BT
8-Channel In / 8-Channel Out Digital Sound Processor with Bluetooth
If you’re serious about car audio and want to dial in the audio reproduced by your components use DS18’s DSP8.8BT: your system’s new command center.
Total Control
The DSP8.8BT gives you full 8-in/8-out signal control with pro-grade tools right out of the box. You’ve got a 31-band graphic EQ, fully adjustable crossovers (6–48dB/octave), delay, phase control, gain tweaks—everything you need to get that perfect balance.
App-Tuned
Control everything wirelessly through the DSP8.8BT App for iOS or DSP8.8BT App for Android. Set it from your driver’s seat. Dial in your front stage, rear fill, and sub timing in real-time. Save custom presets for your favorite genres or switch between tuning setups with a tap.
Tuned By You, For You
Want more punch in your vocals? This processor gives you surgical-level precision so you can tweak your sound exactly how you like it. Save 10 presets and instantly switch between them depending on what you’re listening to.
Absolute Unit
You’re working with 32-bit DSP processing, real-time data sync, high-voltage RCA outputs (up to 8V), and a smooth Bluetooth connection. No matter what you’re running, this unit can handle it.
Fast free shipping
30-days returns
2 year warranty
Secure payment
8-Channel In and 8-Channel Out Digital Sound Processor (DSP) with Bluetooth
Key Features
- Digital Sound Processor
- 8 Channel In
- 8 Channel Out
- Remote Output
- Bluetooth Connectivity Via App
- IOS and Android Compatible
